10225-186 - 5 Drawer Top Box 186Pc Met / Imperial Tool Kit

LENGTH (mm): 690
WIDTH (mm): 460
HEIGHT (mm): 490
WEIGHT (kg): 76

Content:

5 Drawer Heavy Duty Top Box with 186Pc Tools Metric/Imperial

Roller bearing
Auto Drawer Retention System
Safety lock drawers (only One drawer at a time can be opened)
Industrial Powder Coating
Full depth Removable Drawers

Tool Contents:
T2641-15 64pc 1/4" 6pt. Std & Deep socket set Hex Keys
1/4"DR.
14-6pt. Flank socket
3.2;4;4.5;5;5.5;6;7;8;9;10;11;12;
13;14mm
9-6pt. Flank deep socket
5;6;7;8;9;10;11;12;13mm
24-Socket bit(32mmL)
Hex 3;4;5;6;7;8;10mm
Phillips PH.1;PH.2;PH.3
Pozidriv PZ.1;PZ.2;PZ.3
Slotted 4;5.5;6.5mm
Star T8;T10;T15;T20;T25;T27;
T30;T40
1-20 teeth Ratchet handle
3-Extension 2" & 4"&6"
1-Sliding T handle
1-Universal joint
1-Spinner 6"
1-Magnetic socket pick-up
10-Hex ball point key(Long pattern)
1.27;1.5;2;2.5;3;4;5;6;8;10mm

T2084B - 8pc Screwdriver Set
6-Anti-Slip Slotted Screwdrivers
3mm(75mmL)
3.5mm(100mmL)
4mm(100mmL)
5.5mm(125mmL)
6.5mm(150mmL)
8mm(175mmL)
2-Anti-Slip Phillips Screwdrivers
PH.1(80mmL)
PH.2(100mmL)

T5082 - 8pc Flare nut wrench set (Metric)
8-Flare nut wrench
8x10;11x13;12x14;16x18;17x19;
19x22;24x27;30x32mm

T3322-15 - 32pc 3/8" Socket Set (Metric & SAE)
3/8"DR.
17-6pt. Flank socket(MM)
6;7;8;9;10;11;12;13;14;15;16;17;
18;19;20;21;22mm
7-6pt. Flank socket(SAE)
1/4";3/8";1/2";9/16";5/8";11/16";13/16"
3-Extension
75-3";150-6";225-9"
1-Adaptor for extension
1/2"(F) x 3/8"(M)
1-Universal joint
1-30 Teeth Ratchet handle
2-Spark plug socket
16mm; 20.6mm

1-Universal joint
1-Swivel handle 15"

T40612 - 6pc 1/2" Accessory Set
1/2"DR.
1-36 Teeth Ratchet Handle
2-Extension 125mmL & 250mmL
1-Sliding T Handle

T4212 - 21pc 1/2" 6pt. Flank Socket Set (Metric)
21-6pt. Flank socket
8;10;11;12;13;14;15;16;17;18;19;20;
21;22;23;24;26;27;28;30;32mm
T5161 - 16pc Combination Wrench Set
16-Combination wrench
6;7;8;9;10;11;12;13;14;15;16;17;
18;19;22;24;mm

T5085 - 8pc 45 offset ring wrench (Metric)
8-45°Offset ring wrench
8x9;10x11;12x13;14x15;16x17;
18x19;21x23;22x24mm

T5043A - 4pc Snap Ring Pliers Set
4-Snap Ring Pliers
External Straight Tip 1.8mm(open)
Internal Straight Tip 1.8mm(close)
External 90°Bent Tip 1.8mm(open)
Internal 90°Bent Tip 1.8mm(close)

T5045 - 4pc Combination Plier Set
1-Long Nose Pliers 8"
1-Combination Pliers 7"
1-Diagonal Pliers 7"
1-Slip Joint Pliers 8"

T5038 - 3pc Combination Plier Set
1-Adjustable Wrench 10"
1-Waterpump Pliers 10"
1-Locking Pliers

904U5 - 4Pc Pry Bar Set
Sizes Include
8" Bar
12" Bar
18" Bar
24" Bar

T50822 – 8pc Hammer and Chisel Set (500gm)
1-Chisel 12mm (150mmL)
1-Cape chisel 150mm
1-pin punch 4mm (190mmL)
1-Taper punch 3mm (185mmL)
1-Center punch 4mm (185mmL)
1-Engineers hammer 500g
1-20pcs feeler gauge set
(Included 20blades 0.05mm to 1.00mm)
1-Gasket scraper

Drawer Contents

View Drawer 1

View Drawer 2

View Drawer 3

View Drawer 4
